#358224 - 02/14/12 11:38 PM Fender extensions
bdoubleu Offline
Junior Member

Registered: 02/14/12
Posts: 75
Loc: Avon, Indiana
Need help identifying if my 71 Monte has the core support of a 70?
_________________________

Top
#358230 - 02/15/12 12:01 AM Re: Fender extensions [Re: bdoubleu]
robs70monte Offline
Monte Man
Bronze Member

Registered: 01/08/11
Posts: 559
Loc: Fulton,NY
You cant put 1971 fender extensions on a 70 core support 70 is all on its own
_________________________

Sweet Signature made By Lucky Kenny

Top
#358242 - 02/15/12 12:20 AM Re: Fender extensions [Re: bdoubleu]
bdoubleu Offline
Junior Member

Registered: 02/14/12
Posts: 75
Loc: Avon, Indiana
Would the 70 extension match up with the fender of a 72
_________________________

Top
#358243 - 02/15/12 12:21 AM Re: Fender extensions [Re: bdoubleu]
bdoubleu Offline
Junior Member

Registered: 02/14/12
Posts: 75
Loc: Avon, Indiana
Sorry meant 71
_________________________

Top
#358246 - 02/15/12 12:27 AM Re: Fender extensions [Re: bdoubleu]
black07ss Online   sad
I wish I had an easy button
Diamond Member

Registered: 09/28/09
Posts: 5133
Loc: Lorain, Ohio
I don't think so. I believe the dowel is different for the 70 also the 70 has a round headlight bezel and the 71 is square. What are you looking for? lots of spare parts to be had here. Post what you need in the for sale/ wanted section.
_________________________


Bob

Top
#358248 - 02/15/12 12:28 AM Re: Fender extensions [Re: bdoubleu]
robs70monte Offline
Monte Man
Bronze Member

Registered: 01/08/11
Posts: 559
Loc: Fulton,NY
yes you can inter change 71 and 72 extensions and other front end parts but it requires modification many never done it tho
_________________________

Sweet Signature made By Lucky Kenny

Top
#358252 - 02/15/12 12:41 AM Re: Fender extensions [Re: bdoubleu]
bdoubleu Offline
Junior Member

Registered: 02/14/12
Posts: 75
Loc: Avon, Indiana
My issue is I got 71 extenstions, but they seem to be blocking the headlight a bit.So I thought perhaps the previous owner replaced the core with that of a 70.
_________________________

Top
#358253 - 02/15/12 12:45 AM Re: Fender extensions [Re: bdoubleu]
Sam (Bones) Offline
monteholic moderator
Double Diamond Member

Registered: 07/25/04
Posts: 15643
Loc: Ortonville,Mi
actually there are about three different core supports per each year eek
there are some very good threads about this, use our search feature to look for them, explaining this is very lengthy lol
_________________________


Sam
http://www.youtube.com/watch?v=42fGh6B82oc


Top
#358285 - 02/15/12 02:33 AM Re: Fender extensions [Re: bdoubleu]
Canuck Offline
FGMCC Western Meet Coordinator
Chrome Member

Registered: 07/25/02
Posts: 9065
Loc: Summerland, BC, Canada
If the headlights are not lining up with the fender extensions, it's very likely you have a 70 core support.

Your options are to finmd a 71 core support, but 1970 front end parts (extensions, grill, bumper) or try to modify the core support you have to fit 1971 parts. In my opinion, I probably wouldn't try modifying the core support.

As for the different types of core supports (within the same odel year) out there, they had one for a small rad (not very common) and a larger rad. So, in 1970 there are 2 types and in 71 there are 2 types. I think 72 they all had the same support which is the same as the larger rad support for 71.

The reason for the differene between the 1970 support and the 71/72 support is that they decided to move the headlights outwards a little bit for 71. The headlight was now located directly below one of the bolts that holds down the fender so they had to move it up about 1/2 inch higher. The area where the fender bolts to the core support is flat in 1970 but in 71/72 they had to create a "step" for the fender bolt above the headlight.
_________________________
Aaron
1970 Misty Turquoise Monte Carlo - 104,000 miles
1971 Cranberry Red SS454 Monte Carlo - 102,000 miles



2015 FGMCC WESTERN MEET INFO: click here

Top
#358289 - 02/15/12 03:32 AM Re: Fender extensions [Re: bdoubleu]
bdoubleu Offline
Junior Member

Registered: 02/14/12
Posts: 75
Loc: Avon, Indiana
then would a 70 grill,ext and bumper work? defintely don't want to try and modify anything and ruin this rusty beauty.
_________________________

Top
